Keylink Microwave X band SSPA module-8.9-9.6GHz
Keylink's SSPA(solid state power amplifier) module - KBP8996M53A is an X-band high power pulsed amplifier operating in the 8.9 to 9.6GHz frequency range and offering pulsed width up to 100uS withduty cycle up to 15%. The rf amplifier provides in excess of 200 Watts peak output power into a 50 Ohm load. The employment of gallium nitride (GaN) and chip-and-wire technology in manufacturing ensures this module state-of-the-art power performance with excellent power-to-volume ratio. It is ideal for high power pulse applications or Radar system.
-
Pulsed Operation
-
200Watts Peak Pulsed Power
-
Small Size and Light Weight
-
Power Added Efficiency＞20%
-
Digital Interface Option
-
Pulse Width/duty Cycle Protection
-
Over Temperature Protection
-
Over Voltage, and Over Current Monitoring.
-
VSWR Tolerance 3:1
