X-Band Power Amplifier: KeyLink's 8-12GHz 20W, 50W, 100W Broadband Power Amplifier Series

KeyLink's X-band power amplifier series offers a range of power levels, from a compact 20W to a high-power 100W, providing precisely matched RF solutions for radar, communications, and electronic countermeasures applications.

In X-band (8-12GHz) RF applications, power requirements vary significantly across different scenarios. KeyLink's three 8-12GHz wideband power amplifiers, offering 10W, 50W, and 100W power ratings, enable customers to precisely select the right amplifier for their application, avoiding wasted resources or inadequate performance.

KB80120M43C: 20W Power Amplifier

 Designed for space-constrained and low-power applications, it maintains full 8-12GHz frequency coverage while offering a compact design and efficient heat dissipation. It is suitable for portable test equipment and unmanned aerial vehicles (UAVs).

 1. Size: 160x120x20mm

2. Weight: 1kg

3. In Stock

KB80120M47C: 50W Power Amplifier

 This 50W power amplifier achieves an optimal balance between power and size, meeting the power requirements of ground communication relays and mobile radars while maintaining a moderate size and power consumption, making it an ideal choice for most fixed and mobile platforms.

1. ±1dB gain flatness

2. Size: 160x120x20mm

3. Weight: 1kg

4. In Stock

 KB80120M50BV: 100W Power Amplifier

This amplifier provides ample power reserve for the final amplification stage of radar transmit chains and long-range jamming systems. Enhanced heat dissipation and multiple protection mechanisms ensure excellent reliability under continuous high-load operation.

1. ±1dB gain flatness

2. Forward and reverse power detection

3. Standing wave protection

Common advantages across the entire product line

1. Full X-band coverage: Ensures flat gain and stable output from 8-12 GHz

2. Comprehensive protection mechanisms: Built-in overvoltage, overcurrent, and overtemperature protection

3. Compact, standardized structure: Enables rapid integration and system upgrades

 Typical application scenarios

l Military radar and electronic countermeasure systems

l Satellite communication ground station uplinks

l Microwave relays and test and measurement equipment

l Scientific research and target simulators

KeyLink provides technical documentation, field-tested data, and customized services for its entire product line. Please visit the official product page for detailed specifications or contact our sales team to request a sample test.

Contact email: info@keylinkmw.com

Sales support: +86 181 0903 7151
