Broadband High Power Amplifier Module 8-12GHz/50Watts
The model KB80120M47A is a high rf power amplifier operating between 8000 MHz and 12000 MHz and offering a wide dynamic Range with 50 Watts typical saturated power.The employment of advanced high power devices in manufacturing ensures this module exceptional power performance, long term reliability and high efficiency. It is ideal forbroadband high power X Band linear applications.
FEATURES:
-
Small Size 160x120x22mm [6.3x4.7x0.86 inch];
-
light weight 0.94 kg;
-
Instantaneous ultra broadband;
-
50 Ohms input and Output matched;
-
Built-in control and protection circuits.
TYPICAL APPLICATIONS:
» Jamming system;
» Test equipment;
» Communication systems.
|
Parameter |
Value |
Notes |
|
Operating Frequency |
8-12GHz |
|
|
RF Output Power @PSAT |
50 Watts |
Typical |
|
Power Gain @PSAT |
47dB |
Typical |
|
Power Gain Flatness |
±2 dB |
|
|
Input Return Loss |
-10 dBm |
Maximum |
|
Harmonics @50W |
-25dBc |
Typical |
|
Spurious Signals |
-60dBc |
Typical |
|
Switch On/Off@10-90% Time |
2μs |
Typical |
|
In/Output Impedance |
50Ω |
Typical |
|
Operating Voltage |
24V |
Typical |
|
DC Current @40W |
13A |
Typical |
