RF Broadband High Power Amplifiers KB0727M43B

RF Broadband High Power Amplifiers KB0727M43B

Model No. : KB0727M43B

KeyLink's rf broadband power amplifier KB0727M43B is operating between 700 - 2700MHz with output power 20W. Our rf broadband amplifiers can cover frequencies from 1 MHz to 18 GHz and output power up to over 500W.

Start : 700 MHz Stop : 2700 MHz Pout : 20 Watts Gain : 43 dB Voltage : 28 V Current : 4 Amp Mode : CW Size : 150x90x22 mm

KeyLink's broadband high power amplifiers are available for operating frequencies from 1 MHz to 18 GHz. Power levels for octave and multi-octave designs range from 2 watts to over 500 watts. Based on state-of-the-art GaN, GaAs, LDMOS power devices and MMICs, KeyLink designs and manufactures SSPA(solid state power amplifiers ) with excellent performance in terms of high efficiency over ultra-wide working band, high reliability and ruggedness.

Features of KeyLink's high power amplifiers make them suitable for a variety of application fields including jamming, communication, test and radar systems where smaller size, less power consuming, cooling, high output power are required.

May we also suggest

Model No.
Data Sheet
Start(MHz)
Stop(MHz)
Pout(Watts)
Gain(dB)
Voltage(V)
Mode
Size(mm)
Quote
RF Broadband High Power Amplifiers KB0727M43B
KB0727M47C
700
2700
50
47
28
CW
162.6x86.4x25
Get Quote Stock 6
RF Broadband High Power Amplifiers KB0727M43B
KB0727M49A
700
2700
80
49
28
CW
180x90x25
RF Broadband High Power Amplifiers KB0727M43B
KB0727M50A
700
2700
100
50
28
CW
180x90x25
Get Quote Stock 3
RF Broadband High Power Amplifiers KB0727M43B
KB0727S45A
700
2700
30
45
100~260VAC
CW/FM/AM
19'', 2U
RF Broadband High Power Amplifiers KB0727M43B
KB0810M47A
800
1000
50
47
28
CW
150x90x25
Get Quote Stock 1
RF Broadband High Power Amplifiers KB0727M43B
KB0810M53A
800
1000
200
53
28
CW
200x150x25
RF Broadband High Power Amplifiers KB0727M43B
KB1017M43A
1000
1700
20
43
28
CW
140×85×20.5
RF Broadband High Power Amplifiers KB0727M43B
KB1020M47A
1000
2000
50
47
28
CW
150x90x25
Get Quote Stock 2
RF Broadband High Power Amplifiers KB0727M43B
KB1020M50A
1000
2000
100
50
28
CW
180x120x25
RF Broadband High Power Amplifiers KB0727M43B
KB1020M53A
1000
2000
200
53
28
CW
200x150x25
RF Broadband High Power Amplifiers KB0727M43B
KB1020S55A
1000
2000
300
55
100~260VAC
CW/FM/AM
19'', 5U
RF Broadband High Power Amplifiers KB0727M43B
KN2350M53A
2300
2500
200
53
28
CW
200x150x30
RF Broadband High Power Amplifiers KB0727M43B
KN2400M47A
2300
2500
50
47
28
CW
150x90x25
RF Broadband High Power Amplifiers KB0727M43B
KN2450M47A
2400
2500
50
47
28
CW
150x90x25
RF Broadband High Power Amplifiers KB0727M43B
KN2450M50A
2400
2500
100
50
28
CW
170x130x30
RF Broadband High Power Amplifiers KB0727M43B
KN2450M53A
2400
2500
200
53
28
CW
170x130x30
RF Broadband High Power Amplifiers KB0727M43B
KNP1300M60A
1200
1400
1000
60
50
pulse
260x240x30
RF Broadband High Power Amplifiers KB0727M43B
KNP1300S57A
1200
1400
500
57
100~260VAC
Pulse
19'', 2U
